TRNC[G]-7-60 | 2G/3G/4G Rail Antenna with optional GNSS
- The TRNC(G) antenna series is designed specifically for use on trains, trams, and busses underground and overground. Incorporating a DC grounded element operating wideband across all frequencies from 698MHz to 6000MHz, the TRNC(G) range is versatile and future proof.
Features
- SiSo Wideband Cellular LTE Antenna
- Heavy Duty & Fully Rail Certified Antenna
- Built to the Standard 4-hole Fixing Position
Product Overview
Description
Part Numbers
Specification
Accessories
Description
The TRNC(G) antenna series is designed specifically for use on trains, trams, and busses underground and overground.
Incorporating a DC grounded element operating wideband across all frequencies from 698MHz to 6000MHz, the TRNC(G) range is versatile and future proof. The TRNC(G) series covers GSMR, 700MHz LTE, 800MHz TETRA, and trunking bands along with all cellular and GSM frequencies, 2.4 & 5.8GHz WLAN, 2.6 GHz LTE, and WiMAX all in one housing. in versions with a GPS module, the module is protected by a gas discharge surge arrestor.
Housed in a high impact, flame retardant Ultem housing, the TRNC(G) series is weatherproof ensuring that the antenna’s performance is never compromised. The TRNC[G]-7-60 meets stringent industry standards including EN50I55, EN45545-2 (HLI-3), EN50124 (40 KA 100 MS) and is ingress protected to IP69K when properly installed.
Incorporating a DC grounded element operating wideband across all frequencies from 698MHz to 6000MHz, the TRNC(G) range is versatile and future proof. The TRNC(G) series covers GSMR, 700MHz LTE, 800MHz TETRA, and trunking bands along with all cellular and GSM frequencies, 2.4 & 5.8GHz WLAN, 2.6 GHz LTE, and WiMAX all in one housing. in versions with a GPS module, the module is protected by a gas discharge surge arrestor.
Housed in a high impact, flame retardant Ultem housing, the TRNC(G) series is weatherproof ensuring that the antenna’s performance is never compromised. The TRNC[G]-7-60 meets stringent industry standards including EN50I55, EN45545-2 (HLI-3), EN50124 (40 KA 100 MS) and is ingress protected to IP69K when properly installed.
Part Numbers
| SKU | Colour | Cellular | GPS | TRNC-7-60 | Black | SiSo | No |
|---|---|
| N (f) | TRNCG-7-60 | Black | SiSo | 1 Module |
| N (f) | TNC (f) |
Specification
| ELECTRICAL DATA | |
|---|---|
| Pattern | Omnidirectional |
| Max Input Power(W) | 60 |
| Frequency Range | Gain | 698 – 960MHz | 5dBi; 1710 – 2700MHz | 7dBi; 4900 – 6000MHz | 10dBi |
| Cellular LTE Elements | SiSo |
| WIFI Elements | No |
| UHF Elements | No |
| GPS DATA | |
| GPS Frequency Range | 1560-1612MHz |
| LNA GAIN (dB) | 26 |
| Number of GPS Elements | No; 1 Module |
| MECHANICAL DATA | |
| Colour | Black |
| Length | 260 (mm) | 10.24 (in) |
| Width | 87 (mm) | 3.43 (in) |
| Height | 110 (mm) | 4.33 (in) |
| Operating Temperature | -40°/ +80°C (-40.0°/ +176.0°F) |
| TERMINATION DATA | |
| Connector (GPS) | TNC (f) |
| Connector (LTE) | N (f) |
| MOUNTING DATA | |
| Mounting Type Fixed | Panel |
| Mounting Methods | Panel |
| APPROVALS DATA | |
| IP Rating | IP69K; IP67 | TECHNOLOGY DATA |
| Technology | 4G/5G; 5G; 2G/3G; 2G/3G/4G; Band 71 600MHz ready; GPS; GNSS |
Accessories
Product Features
Benefits
Application
Product Features
- SiSo Wideband Cellular LTE Antenna
- Heavy Duty & Fully Rail Certified Antenna
- Built to the Standard 4-hole Fixing Position
- Covers Wideband 700-6000MHz for Cellular LTE
- GSM-R or WiFi
- Optional GNSS Version Available
- DC Grounded Antenna
- Certified to EN50155
- EN45545 (HL 1-3)
- EN50124-1 (25KA / 100ms) and IP69K
Benefits
- Ideal Antenna for Trains
- Trams
- Light Rail and Buses
- Low Profile Combination Antenna
Application
- Mass Transit
- Rail
