Antennas for trackside communications
Complementing our antennas for rolling stock, tram, and light rail use, Panorama Antennas can also supply products for trackside applications, including antennas for equipment cabinets, operations monitoring and control, station platform WiFi, and a vast array of other purposes.
Durable antennas designed for demanding trackside connectivity
Trackside antennas cover a variety of different requirements. One key area is monitoring and control of equipment located by the tracks, using either cellular or unlicensed (ISM) frequency bands like 433, 868, or 915MHz. Additionally, there may be platform based ticketing or vending machines which are accessed and used by the public. A final example is trackside WiFi or cellular coverage distribution, either in or around station concourses or tunnels.
The common feature of these applications is that they require durable antenna solutions which can withstand both long, maintenance free periods in exposed locations, and potential vandalism or unintentional damage from various sources. Depending on the application, the antennas may also require rail industry or other approvals.
Key benefits
Fit for purpose solutions
Panorama Antennas offers a wide range of lower-cost, easy to install products for 433, 868, or cellular bands for trackside cabinets, through higher specification cellular and multifunction antennas for vending and ticketing machines or ceiling or wall-mounted, rail approved antennas for cellular and WiFi coverage.
Durable solutions
Robust weather, UV and impact resistant housings combined with high levels of ingress protection ensure that our antennas retain their functionality in the long term with minimal maintenance.
Rail industry approvals
Where required, we have antenna platforms approved to the major rail industry standards, including EN50155 and EN45545-2.
Antennas for trackside cabinets
LPAB-868
Ultra-low profile panel mount antenna
The LPAB offers an ultra-low profile, robust housing covering 868MHz and includes several features designed to make it more resistant to vandalism.
LPW-BC3G-26
Low-profile wall or cabinet mounted antenna
The popular LPW range offers a cost-effective cabinet mount solution with multiple installation and cable routing options. The LPW-BC3G-26 covers 4G/LTE bands, but versions are also available for 433MHz and 868MHz bands.
B4BE-6-60
Wideband bracket mount antenna
The B4BE range has been designed to provide cost-effective coverage booster antennas for 4G/5G devices. The antenna is designed for wall or mast mounting and is both robust and weatherproof.
Antennas for ticketing and vending machines
LP[G]AM-BC3G-26
Compact cellular IoT antenna
The LP[G]AM-BC3G-26 range has been designed to provide a cost effective MiMo 4G/LTE antenna solution for IoT and M2M applications. The sleek fin shaped housing is weatherproof and contains two antennas covering all current global cellular and LTE bands across 698-960/1710-3800MHz.
![LPM2-7-27[-X] | Low Profile MiMo 4G Antenna](https://panorama-antennas.com/wp-content/uploads/2023/09/PIC_LPM2-7-27.png)
LPM2-7-27
Ultra-low profile cellular IoT antenna
The LPM2-7-27 range has been designed to provide MiMo 4G/LTE operation in an ultra-low profile package. The compact, robust, low-profile housing is weatherproof and contains two antenna elements covering 698-960/1427-2700MHz.
Clam®
Panel-mount IoT antenna
The L[X]A[X]M4-7-42[-X] MiMo antenna is designed to be a one size fits all solution for IoT applications. The robust low-profile housing contains 4x 4G LTE/5G NR elements covering 698-960/1427-4200MHz. Versions of the product also contain up to 4x WiFi elements for WiFi 6e/7 2.4/5.150-7.125GHz and optional L1 only or L1/L5 GPS/GNSS. Magnetic mount version also available.
Antennas for station WiFi coverage
LPM[X]W-24-72
Ultra compact dome antenna
An ultra compact dome antenna supporting up to 4×4 WiFi 6e/7. The antenna is approved to EN45545-2, EN50155, IP69K and IK10. The low height enables internal installation in low height clearance areas.
WMM[X]9G-24-72
High gain directional antenna
The WMM[X]9G-24-72 is a robust directional 2×2, 3×3 or 4×4 MiMo antenna covering 2.4-7.125GHz. The antenna is approved to EN45545-2, EN50155, IP69K and IK10. The antenna is easy to install and ideal for station platform coverage.
W24-58-CP-9
SiSo directional antenna
The W24-58-CP-9 is a SiSo directional wall or mast mount antenna covering 2.4 & 5GHz for WiFi applications. This antenna can be used to cover a wide area thanks to its relatively wide beamwidth in the horizontal and vertical planes.
